Rockwell Automation 20B PowerFlex 700 Drives - Frame 10 Components Replacement User Manual
Page 33
Rockwell Automation Publication 20B-IN026B-EN-P - July 2013
33
Basic Component Removal Procedures
Chapter 2
16. Reinstall the DC Choke output cables.
17. Reinstall any customer wiring to the Transitional Busbar assembly.
18. Reinstall the Stacking Panel as instructed on page
19. Reinstall the Main Control Panel as instructed on page
20. Verify all wiring to the two panels and the Transitional Busbar assembly
has been reconnected.
21. Replace all safety shields and enclosure covers before applying power to the
drive.
