Appendix: Technical Specifications 68
Parameter Full scale Accuracy, % Range Display resolution (%Rdg)
@ input Rdg FS Conditions @ range
1 kVAh @ 1 to 999,999,999 kVAh
RPM096:
1 kVAh @ 1 to 999,999 kVAh
10 kVAh @ 1000 to 9,999.99 MVAh
100 kVAh @ 10,000 to 99,999.9 MVAh
1MVAh @ 100,000 to 999,999 MVAh
Volt-hours 0 to 999,999.999 kVh PM296:
1 Vh @ 1 to 999,999,999 Vh
RPM096:
1 Vh @ 1 to 999,999 Vh
10 Vh @ 1000 to 9,999.99 kVh
100 Vh @ 10,000 to 99,999.9 kVh
1kVh @ 100,000 to 999,999 kVh
Ampere-hours 0 to 999,999.999 kAh PM296:
1 Ah @ 1 to 999,999,999 Ah
RPM096:
1 Ah @ 1 to 999,999 Ah
10 Ah @ 1000 to 9,999.99 kAh
100 Ah @ 10,000 to 99,999.9 kAh
1kAh @ 100,000 to 999,999 kAh
Key:
PT = external potential transformer ratio CT, CT Primary Current = primary current rating of external current transformer
FSU = voltage full scale FSI = current full scale U1 = voltage fundamental I1 = current fundamental
@ 80% to 120% of voltage FS and 1% to 200% of current FS
@ 10% to
< 80% of voltage FS and 1% to 200% of current FS
Higher resolution is achievable via communications
Additional Notes
1. Accuracy is expressed as ± (percentage of reading + percentage of full scale) ± 1 digit. This does not include inaccuracies introduced by
the user's potential and current transformers.
2. Specifications assume: voltage and current wave forms with THD ≤ 5% for kvar, kVA and PF; reference operating temperature: 20 - 26°C.
3. Measurement error is typically less than the maximum error indicated here.
