Chapter 6 Viewing Status Information
54
6.2 Status Display Formats
Tables 6-1 and 6-2 list all the displays available from the Status Information
Menu
.
The PM296 Status Display
The display windows are labeled in the table in the direction up-to-down and left-
to-right.
Table 6-1 Status Information Display for the PM296
Page Window Parameter Digits Unit
1 4
PHAS.
Label
1 5
rOt.
Label
1
6
Phase rotation (POS/NEG/ERR)
4
2 4
AnGL
Label
2
1
Phase L1/L12 angle
4
Degree
2
2
Phase L2/L23 angle
4
Degree
2
3
Phase L3/L31 angle
4
Degree
3 1
rEL.
Label
3 2,5
1.2.3.4.5.6.
Label
3
4,6
Relay #1-6 status
6
4 1
St.In
Label
4 3,6,9
1.2.3.4.5.6.7.8.9.A.b.C
Label
4
3,6,9
Status inputs #1-#12
4
7 1
Cnt.1
Label
7
3
Counter #1
6
. . .
22 1
Cn.16
Label
22
3
Counter #16
6
23 1
bAtt
Label
23
3
The battery status (NORMAL/LOW)
The RDM096 Status Display
The display windows are labeled in the table as follows: 1 = upper window, 2 =
middle window, 3 = lower window.
Table 6-2 Status Information Display for the RDM096
Page Window Parameter Digits Unit
1 1
PHAS.
Label
1 2
rOt.
Label
1
3
Phase rotation (POS/NEG/ERR)
4
2 1
rEL.
Label
2 2
1.2.3.4
Label
2
3
Relay #1-4 status
4
