Chapter 4 Setup Menus 36
To select a display option:
Press to activate the middle window, and then use the up/down arrow keys to
scroll to the desired option.
To change the display option:
Press to activate the lower window.
Use the up/down arrow keys to set the desired option.
Press to store your new setting or press to leave your previous setting
unchanged.
To quit the display setup menu:
From the middle window, press or .
4.11 User Selectable Options Menu
This menu allows you to change options which relate to the instrument features
and functionality. Table 4-7 lists all available options with their code names and
applicable ranges.
To select an option:
Press to activate the middle window, and then use the up/down
arrow keys to scroll to the desired option.
To change the selected option:
Press to activate the lower window.
Use the up/down arrow keys to set the desired value.
Press to store your new setting or to leave the previous
setting unchanged.
To quit the display setup menu:
From the middle window, press or .
Table 4-7 User Selectable Options ( ∗ default setting )
Code Parameter Options Description
P.cAL Power calculation
mode
rEAc
∗
nAct
Using reactive power
Using non-active power
thr.d Thermal demand
calculation
diS
∗
, En
Disables/enables thermal power demand
measurement
roLL Energy roll value 10.E4
10.E5
10.E6
10.E7
10.E8
10.E9
∗
10,000 kWh
100,000 kWh
1,000,000 kWh
10,000,000 kWh
100,000,000 kWh
1,000,000,000 kWh
OPtS
rEAc
P.cAL
SELECT
SELECT
SELECT
SELECT
ESC ENTER
ESC ENTER
ESC ENTER
ESC ENTER
SELECT CHG OPtS ENTER ENTER
