Chapter 5 Data Display 44
Page Window PAGE Parameter Digits Unit
LEDs
1 9 Total kvar 5 kvar/Mvar
1 10 Total kVA 5 kVA/MVA
1 11 Total power factor 4
2 11 PAG.1 Label
2 7 L-L Label
2 1 Voltage L12 4 V/kV
2 2 Voltage L23 4 V/kV
2 3 Voltage L31 4 V/kV
3 7 Ph.L1 Label
3 1 Voltage L1/L12 4 V/kV
3 4 Current L1 4 A
3 8 kW L1 5 kW/MW
3 9 kvar L1 5 kvar/Mvar
3 10 kVA L1 5 kVA/MVA
3 11 Power factor L1 4
4 7 Ph.L2 Label
4 2 Voltage L2/L23 4 V/kV
4 5 Current L2 4 A
4 8 kW L1 5 kW/MW
4 9 kvar L2 5 kvar/Mvar
4 10 kVA L2 5 kVA/MVA
4 11 Power factor L2 4
5 7 Ph.L3 Label
5 3 Voltage L3/L31 4 V/kV
5 6 Current L3 4 A
5 8 kW L3 5 kW/MW
5 9 kvar L3 5 kvar/Mvar
5 10 kVA L3 5 kVA/MVA
5 11 Power factor L3 4
Maximum Demand Measurements
6 11 PAG.2 Label
6 1 Maximum volt demand L1/L12 4 V/kV
6 2 Maximum volt demand L2/L23 4 V/kV
6 3 Maximum volt demand L3/L31 4 V/kV
6 4 Maximum ampere demand L1 4 A/kA
6 5 Maximum ampere demand L2 4 A/kA
6 6 Maximum ampere demand L3 4 A/kA
6 8 Maximum sliding window kW import
demand 5 kW/MW
6 9 Maximum sliding window kvar
import demand 5 kvar/Mvar
6 10 Maximum sliding window kVA
demand 5 kVA/MVA
Total Harmonic and Auxiliary Measurements
7 11 PAG.3 Label
7 1 Voltage THD L1/L12 4 %
7 2 Voltage THD L2/L23 4 %
