Chapter 5 Configuring the EM920
General Meter Setup
EM920 Power Quality and Revenue Meter 85
Display Label Parameter Options Default Description
Auto-Scroll Auto-Scroll
Interval
Disabled,
2-10, 15, 20, 25, 30
seconds 5 Defines the display scroll
interval or disables auto-
scroll
Scroll Sequence Auto-Scroll
Sequence 1
1-2
1-3
1-4
1-5
1-6
1-6, 10
1-6, 10-11
1-6, 10-12
1, 5, 10-12
1-2, 5, 10-12
1-3, 5, 10-12
1, 6, 10-12
1-2, 6, 10-12
1-3, 6, 10-12
1-4, 6, 10-12
1, 10-12
1-2, 10-12
1-3, 10-12
1-4, 10-12
1, 11-12
1-2, 11-12
1-3, 11-12
1-4, 11-12
1, 12
1-2, 12
1-3, 12
1-4, 12
1, 12 Selects the display
sequence for auto-scrolling
from 12 data displays
(see
Data Displays for
display enumeration)
Auto-Return Auto-Return Disabled,
1-5, 10, 15, 20, 25, 30
min 5 Defines the time delay
before returning to the
default page
Default Page Default Page 1/2 – 1/10
2/1 – 2/10 …
12/1-12/10 1/2 Specifies the default
display/page. If a page is
not available in present
mode, the following
available page will be
displayed.
Backlight Time Backlight Time Continuous,
1-10 min
1 Defines the time while the
backlight is ON
Diagnostic Icon Diagnostic
Message Icon Disabled
Enabled Enabled Disables/enables the
blinking diagnostic icon in
the data displays
