Appendix A Parameters for Monitoring and Logging
192 EM920 Power Quality and Revenue Meter
Designation Description
ENERGY Instrumentation Total Energy
kWh IMPORT kWh delivered
kWh EXPORT kWh received
kWh NET kWh net
kvarh IMPORT kvarh delivered
kvarh EXPORT kvarh received
kvarh NET kvarh net
kvarh Q1 kvarh quadrant Q1
kvarh Q2 kvarh quadrant Q2
kvarh Q3 kvarh quadrant Q3
kvarh Q4 kvarh quadrant Q4
kVAh TOTAL kVAh total
kVAh IMPORT kVAh delivered (Q1+Q4)
kVAh EXPORT kVAh received (Q2+Q3)
SUMMARY REGS Billing Summary (Total) Energy Registers
SUM REG1 Summary energy register #1
SUM REG2 Summary energy register #2
… …
SUM REG10
Summary energy register #10
%HD V1 V1/V12 Harmonic Distortions 2,3
V1 %HD01 H01 Harmonic distortion
V1 %HD02 H02 Harmonic distortion
… ...
V1 %HD50
H50 Harmonic distortion
%HD V2 V2/V23 Harmonic Distortions 2,3
V2 %HD01 H01 Harmonic distortion
V2 %HD02 H02 Harmonic distortion
… ...
V2 %HD50
H50 Harmonic distortion
%HD V3 V3/V31 Harmonic Distortions
2,3
V3 %HD01 H01 Harmonic distortion
V3 %HD02 H02 Harmonic distortion
… ...
V3 %HD50
H50 Harmonic distortion
%HD I1 I1 Harmonic Distortions 3
I1 %HD01 H01 Harmonic distortion
I1 %HD02 H02 Harmonic distortion
… ...
I1 %HD50
H50 Harmonic distortion
%HD I2 I2 Harmonic Distortions 3
I2 %HD01 H01 Harmonic distortion
I2 %HD02 H02 Harmonic distortion
… ...
I2 %HD50
H50 Harmonic distortion
%HD I3 I3 Harmonic Distortions 3
I3 %HD01 H01 Harmonic distortion
I3 %HD02 H02 Harmonic distortion
… ...
I3 %HD50
H50 Harmonic distortion
%HD I4 I4 Harmonic Distortions 3
