Appendix D Billing and Load Profile Log Files
204 EM920 Power Quality and Revenue Meter
Appendix D Billing and Load Profile Log Files
The following tables show the record structure for the
monthly and daily billing data profile and energy load profile
log files.
The second column shows data abbreviations used in the PAS
data log reports. Data log file sections are highlighted in bold.
Energy Load Profile Data Log (Data Log #12)
Field No. Designation Description
1 REG1 Summary (total) energy register 1 reading
2 REG2 Summary (total) energy register 2 reading
3 REG3 Summary (total) energy register 3 reading
4 REG4 Summary (total) energy register 4 reading
5 REG5 Summary (total) energy register 5 reading
6 REG6 Summary (total) energy register 6 reading
7 REG7 Summary (total) energy register 7 reading
8 REG8 Summary (total) energy register 8 reading
9 REG9 Summary (total) energy register 9 reading
10 REG10 Summary (total) energy register 10 reading
The number of parameters in a record is automatically
configured depending on the number of billing registers for
which you selected a source input in the Billing/TOU Register
setup.
Montly Billing Profile (Billing Period) Data Log (Data Log #15)
Field No. Designation Description
Energy Register #1
1 REG1 Summary (total) energy reading
2 TRF1 Tariff #1 energy reading
3 TRF2 Tariff #2 energy reading
4 TRF3 Tariff #3 energy reading
5 TRF4 Tariff #4 energy reading
6 TRF5 Tariff #5 energy reading
7 TRF6 Tariff #6 energy reading
8 TRF7 Tariff #7 energy reading
9 TRF8 Tariff #8 energy reading
…
Energy Register #10
1 REG10 Summary (total) energy reading
2 TRF1 Tariff #1 energy reading
3 TRF2 Tariff #2 energy reading
4 TRF3 Tariff #3 energy reading
5 TRF4 Tariff #4 energy reading
6 TRF5 Tariff #5 energy reading
7 TRF6 Tariff #6 energy reading
8 TRF7 Tariff #7 energy reading
9 TRF8 Tariff #8 energy reading
Monthly Maximum Demand Register #1
1 REG1 MD Summary (total) max. demand
