Appendix A Parameters for Monitoring and Logging
200 EM920 Power Quality and Revenue Meter
6 The value is calculated using a simplified technique as a
relation of the maximum deviation of phase values from a 3-
phase average value to a 3-phase average.
7 The value is calculated using a simplified technique as a
one third of the RMS value of a 3-phase vector sum.
8 Not affected by loss compensation – always indicate
readings at the metering point.
NOTE
Designations of some enginering demands and billing energy
and demand registers are shown using a new short name
notation available in PAS V1.4. By default, PAS uses long
names compatible with older versions of PAS. You can select
a desired notation from the Tools/Options/Preferences tab.
PAS does not allow to store data in files using different data
names. If you have a file uploaded with a previous version of
PAS using long data names, either continue using long data
names, or store data in a new file.
See table below for a list of parameters with short and long
names.
Short Data
Name
Long Data Name Description
kW IMP ACD kW IMP ACC DMD Accumulated demand
kW IMP PRD kW IMP PRD DMD Predicted sliding window demand
PF IMP@kVA MD PF IMP@kVA MXDMD PF (import) at maximum kVA demand
REG1 ACD SUM REG1 ACC DMD Billing summary (total) register accumulated demand
REG1 BD SUM REG1 BLK DMD Billing summary (total) register block demand
REG1 SD SUM REG1 SW DMD Billing summary (total) register sliding demand
REG1 SUM REG1 Billing summary (total) energy register
REG1 MD SUM REG1 DMD MAX Billing summary (total) register maximum demand
REG1 TRF1 TOU REG1 TRF1 Billing tariff energy register
REG1 TRF1 MD DMD1 TRF1 MAX Billing tariff register maximum demand
TRF1 SEASON TRF1 Generic billing tariff energy register
TRF1 MD SEASON TRF1 Generic billing tariff register maximum demand
