Chapter 1 Introduction 1
Chapter 1 Introduction
1.
1.1 About This Manual
This manual is intended for the user of the C192PF8-RPR Power Factor Manager
and Reactive Power Regulator. The C192PF8-RPR is a multi-function
microprocessor-based instrument used for power factor or reactive power
correction and for the measurement, monitoring, and management of electrical
parameters in low-voltage and mid-voltage power systems.
This chapter gives an overview of this manual and an introduction to the
C192PF8-RPR.
Chapter 2, Installation, provides instructions for mechanical and electrical
installation.
Chapter 3, Using the Menus, presents the structure of menus for setup and status
viewing.
Chapter 4, Setup Menus, provides instructions for performing parameter setup via
the front panel.
Chapter 5, PFC Setup and Operation, provides instructions for performing setup
for the Power Factor Controller (PFC) and describes front-panel operations in
PFC manual mode.
Chapter 6, Data Display, guides you through the display pages.
Chapter 7, Viewing Status Information, tells you how to access additional status
information on the instrument. This information may be useful during installation.
Technical Specifications for the C192PF8-RPR are found in the Appendix.
1.2 About The C192PF8-RPR
The C192PF8-RPR is a compact three-phase AC Powermeter with a built-in
Power Factor Controller (PFC) and Reactive Power Regulator (RPR), designed to
meet the requirements of users ranging from electrical panel builders to
substation operators. The C192PF8-RPR performs power factor or reactive
power correction functions, basic voltage, current, frequency, power, power factor
and energy measurements, plus total harmonic (THD, TDD, K-Factor)
measurements.
The C192PF8-RPR is suitable for mounting on 136 × 136 mm square cut-outs.
Features
Power Factor Controller
• Control of up to 8 capacitor banks
