Chapter 4 Setup Menus 27
Code Parameter Units
rE.EE Reactive energy export kvarh export (capacitive)
rE.Et Reactive energy total kvarh total (absolute)
AP.Et Apparent energy total kVAh total
NOTES
1. You will not be able to store your setup in the instrument if you assigned a parameter
to a relay output with a zero number of unit-hours per pulse.
2. If a relay you allocated for pulsing has been manually operated or released, it reverts
automatically to normal operation.
3. If a relay you allocated for pulsing has been engaged by an alarm/event setpoint, the
setpoint is automatically disabled.
4.6 Alarm/Event Setpoints Setup Menu
Your instrument provides 16 alarm/event setpoints that can monitor a wide variety
of events; in turn, these events can be programmed to trigger specific actions.
This menu is used to specify the events to be monitored by the setpoints, and
actions to be triggered by those events.
To program a setpoint, you might need to define up to six setup parameters which
include: the setpoint trigger parameter, operate and release limits, optional
operate and release delays, and the setpoint action. Table 4-6 explains the
setpoint setup parameters. For the entire list of available triggers and setpoint
actions, refer to Tables 4-7 and 4-8.
Example:
Trigger
parameter
Setpoint 1 is set to monitor the real-time high current
on phase 1 (the trigger parameter).
Operate limit }
}
}
}
Release limit }
The operate (On) and release (OFF) limits which
determine setpoint operation are defined as 1200A
and 1100A respectively.
SP 1
RHi.C1
triG
SP 1
1200
On
SP 1
1100
OFF
SELECT CHG SEtP ENTER ENTER
