Chapter 4 Setup Menus 42
4. The target power factor limits are always specified for the I and IV quadrants regardless
of the location of the instrument on the source or load side. The PFC will automatically
account for the direction of power flow providing full four-quadrant operation.
5. If both target power factor limits are specified for the same quadrant, the high power
factor limit should never be less than the low limit. If the target limits are being set for
two quadrants, the lagging (inductive) power factor should be specified as the low limit
and the leading (capacitive) one as the high target limit. Whenever these relations are
not fulfilled, the instrument will automatically adjust the high target power factor to the
low target limit.
