4.11 Reset/Synchronization Menu
This menu allows you to reset to zero the accumulators and Min/Max registers in
your instrument, and also to synchronize the power demand interval. The menu
can be only accessed via the Setup Change Menu (CHG). If the reset is disabled
from the Basic Setup Menu (see Section 4.1), you will not be able to enter this
menu.
The following designations are used to specify a data location to be affected:
EnrG Resets total accumulated energies
dnd Resets all total maximum demands
P.dnd Resets total power maximum demands
A.dnd Resets volt/ampere maximum demands
Lo.Hi Resets Min/Max registers (does not affect maximum demands)
Cnt Resets all event/time counters
Cnt.1 Resets event/time counter # 1
Cnt.2 Resets event/time counter # 2
Cnt.3 Resets event/time counter # 3
Cnt.4 Resets event/time counter # 4
CYC Resets all PFC relay operation (banks switching cycle) counters
CYC.1 Resets PFC relay operation counter # 1
CYC.2 Resets PFC relay operation counter # 2
CYC.3 Resets PFC relay operation counter # 3
CYC.4 Resets PFC relay operation counter # 4
CYC.5 Resets PFC relay operation counter # 5
CYC.6 Resets PFC relay operation counter # 6
CYC.7 Resets PFC relay operation counter # 7
CYC.8 Resets PFC relay operation counter # 8
d.Snc Provides synchronization of the power demand interval (see NOTES below)
To reset the desired locations:
Press to activate the middle window, and then use the
up/down arrow keys to scroll to the desired data location entry.
Press to activate the lower window.
Press and hold for about 5 seconds until the do label
is replaced with done, and then release the key. You will return
to the middle window.
Press to quit the menu.
NOTES:
1. If changing data in the instrument via the front panel is not secured by a password, fast
reset of the Min/Max registers, maximum demands and energies can be done from the
SELECT CHG rSt ENTER ENTER
SELECT
SELECT
ENTER
rSt
do
EnrG
ESC
