Chapter 4 Setup Menus 25
Table 4-3 Analog Output Setup Options
Code Option Description
OutP Output parameter The output parameter for the analog output channel
Lo Zero scale (0/4 mA) The reading of the parameter corresponding to a zero-
scale current output
Hi Full scale (1/20 mA) The reading of the parameter corresponding to a full-scale
current output
Table 4-4 Analog Output Parameters
Code Parameter Unit Scale
nonE Output disabled 0
Real-time Measurements
r. U 1 Voltage L1/L12 V/kV 0 to Vmax
r. U 2 Voltage L2/L23 V/kV 0 to Vmax
r. U 3 Voltage L3/L31 V/kV 0 to Vmax
r. C1 Current L1 A 0 to Imax
r. C2 Current L2 A 0 to Imax
r. C3 Current L3 A 0 to Imax
r. P Total kW kW/MW -Pmax to Pmax
r. q Total kvar kvar/Mvar -Pmax to Pmax
r. S Total kVA kVA/MVA 0 to Pmax
r. PF Total PF -0.000 to 0.000
r. PF.LG Total PF lag 0 to 1.000
r. PF.Ld Total PF lead 0 to 1.000
r. Fr Frequency Hz 0 to 100.00
Average Measurements
A. U 1 Voltage L1/L12 V/kV 0 to Vmax
A. U 2 Voltage L2/L23 V/kV 0 to Vmax
A. U 3 Voltage L3/L31 V/kV 0 to Vmax
A. C1 Current L1 A 0 to Imax
A. C2 Current L2 A 0 to Imax
A. C3 Current L3 A 0 to Imax
A. P Total kW kW/MW -Pmax to Pmax
A. q Total kvar kvar/Mvar -Pmax to Pmax
A. S Total kVA kVA/MVA 0 to Pmax
A. PF Total PF -0.000 to 0.000
A. PF.LG Total PF lag 0 to 1.000
A. PF.Ld Total PF lead 0 to 1.000
A. neU.C Neutral current A 0 to Imax
A. Fr Frequency Hz 0 to 100.00
Present Demands
Accd.P Accumulated kW demand kW/MW 0 to Pmax
Accd.S Accumulated kVA demand kVA/MVA 0 to Pmax
Imax (20% over-range) = 1.2 × CT primary current [A]
Direct wiring (PT Ratio = 1):
