Beacon 410 Gas Monitor Operator’s Manual
Modbus Menu • 57
2.
Press and release the UP/YES button to continue in the Modbus Menu to the Modbus
Feature Enable/Disable screen.
3.
In the parameter screens, use the ENTER button to accept a displayed parameter
setting and proceed to the next parameter or the ESCAPE button to backup a screen.
4.
If you want to change a displayed parameter setting, use the UP/YES or DOWN/NO
button to change the parameter to the desired setting, then press and release the
ENTER button to accept the change and proceed to the next screen.
5.
Continue through the parameter setting screens changing any parameter settings as
needed until the following message appears on the display.
6.
To save the channel parameter settings, press and release the UP /YES button.The
screen will indicate that the Beacon 410 is saving the settings for a few seconds then
the Beacon 410 will return to normal operation.
If you do not want to save the channel parameter settings, press and release the
DOWN/NO button. The display will indicate that no settings have been changed for a
few seconds then the Beacon 410 will return to normal operation.
Table 11 below lists the Modbus configuration parameters that can be configured in the
Modbus Menu along with the factory set value for each parameter.
Table 11: Modbus Configuration Parameters
Modbus Mode Parameter
Available Settings & Description
Enabled/Disabled
Can be set to ENABLED or DISABLED (factory setting).
Enables or disables the Modbus output.
Slave ID
The Slave ID can be set to values from 1 (factory setting) to 247.
The Beacon 410 will only receive messages from the Master
which are addressed to this Slave ID (except for broadcast
messages which are received by all slaves)
Baud Rate
Can be set to 1200, 2400, 4800, 9600 (factory setting), 14440, &
19200
Parity
EVEN (factory setting), ODD, NONE
S A B L E D
C
S
E
/
T
N
n
e
h
t
N
D
/
E
B
P
O
U
M
D
U S
F e a t u r e
i s :
D I
]
A
C
S
S
s
g
n
i
t
t
?
[
k
t o
b a c
u p
]
E
P
N
Y
[
e
E
a v e
S
/
