Beacon 410 Gas Monitor Operator’s Manual Viewing Maximum Spans • 53
3. Press and hold the ENTER button to display the maximum spans. In the example
below, channels 1, 2, and 3 are active and channel 2 is a 4 - 20 mA type channel.
4. Release the ENTER button to return to the Select Operation screen.
5. Press and release the ESCAPE button to return to the initial Calibration Mode Screen
that says You Have Entered the CALIBRATION Menu... and then press and release
the DOWN/NO button to exit Calibration Mode and return to normal operation.
r
L E L % + 0 1 E N A H T E M 1
2
3 :
:
:
5
3 E O L O :V % 5 . 7 N G Y X
4 - 2 0 m A X m t
