Beacon 410 Gas Monitor Operator’s Manual
Overview • 41
Chapter 7: Input Setup Menu
Overview
This chapter describes how to use the Input Setup Menu to select each channel’s detector
head input type and the gas setup. The detector head input type determines whether a
direct connect type or a 4 - 20 mA type of detector head will be used and the gas setup
determines the target gas, detection units, and the detection range full scale. The Input
Setup Menu is accessed using the ENTER control button when powering up the Beacon
410.
The Input Setup Menu includes a 5-minute timeout feature. If you do not press a button for
5 minutes, the Beacon 410 automatically returns to normal operation.
NOTE:
The Beacon 410 will begin its warm-up sequence when it exits the Input Setup
Menu before it enters normal operation whether because of a program timeout or
because you are done with input setup and are exiting manually.
Selecting the Detector Head Input
Type and Gas Setup
NOTE:
The Beacon 410 must be turned off before you can enter the Input Setup Menu. If
your Beacon 410 is already installed and operating, make sure that turning the
Beacon 410 off will not cause unwanted alarms before continuing.
1.
While the Beacon 410 is off, press and hold the ENTER button, then turn on the
Beacon 410 with the ON/OFF switch.
2.
Continue to press the ENTER button while the Beacon 410 turns on and the display
shows RKI Instruments Beacon 410. Release the ENTER button when the following
screen appears on the display.
3.
If you want to exit the Input Menu, press and release the DOWN/NO button. The
Beacon 410 will exit the Input Menu and begin the warm-up sequence.
If you want to continue in the Input Menu, press and release the UP/YES button. The
Select Channel(s) screen will appear.
u
e
h
T
d
e
r
e
t
n
E
e
v
a
H
u
Y
C
o
o
I
n t i n u e ?
[ Y / N ]
N P U T
S E T U P
M e n
e
l
U
e
P
1
C
E
S
/ D N
t h e n
N T / E S
l
e
n
n
a
h
C
t
c
