12 • Optional Accessories Beacon 410 Gas Monitor Operator’s Manual
Alarm Strobe
The Beacon 410 can be ordered with a red alarm strobe light installed on the top of the
housing. The Beacon 410 retains its NEMA 4X rating with the strobe installed. Strobe
operation can be programmed in Configuration Mode (see “Chapter 6: Configuration
Menu” on page 35). The outline and mounting dimensions with the alarm strobe are the
same as the standard Beacon 410 with the excpetion of the height. The difference is
shown below. See Figure 7 for all outline and mounting dimensions.
Figure 5: Alarm Strobe Dimensions
Horn/Strobe
The Beacon 410 can be ordered with a horn/strobe. This optional horn/strobe allows the
user to have both a strobe and a horn connected to the “Strobe” terminals of the Beacon
410. It also allows the user to mount the horn/strobe away from the Beacon 410 so that it
can be somewhere more visible/audible. Strobe operation can be programmed in
Configuration Mode (see “Chapter 6: Configuration Menu” on page 35).
13.39
Strobe (Optional)
.90
