Code options
3
OPTICON Universal menu book
U73
3.3.17. Options for GS1 Databar
GS1 Databar is formerly known as RSS familiy
including the RSS-14 group. Support for GS1
Databar options is reader dependent.
Maximum data capacity:
• GS1 Databar and GS1 Databar Limited:
Application Identifier "01" and 14 digits.
• GS1 Databar Expanded: 74 numeric or 41
alpha characters
Checksums:
The GS1 Databar family uses a mandatory
checksum.
•GS1 Databar uses a modulo 79 checksum,
•GS1 Databar Limited uses a modulo 89
checksum
•GS1 Databar Expanded uses a modulo 211
checksum.
The checksum is always calculated and is not
transmitted.
Encodable characters:
• GS1 Databar and GS1 Databar Limited:
digits 0 up to 9
• GS1 Databar Expanded: subset of ISO 646:
upper, lower case characters, digits, 20
punctuation characters and function
character FNC1
The next GS1 Databar versions are supported.
• Omnidirectional/Truncated/Stacked
(refer to GS1 Databar)
• Limited (refer to GS1 Databar Limited)
• Expanded, Expanded stacked
(refer to GS1 Databar Expanded)
For string format see figure 3.39 or 3.40.
Options for GS1 Databar:
• transmission of CD
• transmission of Application Identifier
Not transmit CD:
Do not transmit the last character of GS1
Databar.
Fig. 3.39. Options for GS1 Databar
application
identifier (01)
data
(13 digits)
cd
(1 digit)
GS1 Databar,
GS1 Databar Limited
Fig. 3.40. Options for GS1 Databar
data
(1 upto 73 characters)
cd
(1 character)
GS1 Databar Expanded
SET
_ZZ_
Not transmit CD DM
_DM_
Transmit CD DL
_DL_
Not transmit Application
Identifier
DT
_DT_
Transmit Application
Identifier
DS
_DS_
END
_ZZ_
