OPTICON Universal menu book
U114
5.1.1. Multiple read reset time
This option can be used in conjunction with
multiple read mode.
• for Laser and CCD readers, it sets the time
that the reader should be pointed away from
the label before it can decode the same label
again
• for Image readers, it sets the number of
frames that the reader should be pointed
away from the label before it can decode the
same label again
Indefinitely means that the next bar code must
always be different, during the time the bar
code reader is triggered.
For the image reader the multiple reset time is
not measured in ms, but in frames. The
duration of each frame is variable, and is
dependent of the captured image. See figure
5.01.
Fig. 5.01. Multiple read reset time
Multiple
read
reset
time
Frames
50 ms
100 ms
200 ms
300 ms
400 ms
500 ms
600 ms
Indefinitely
1
2
3
4
5
6
7
Indefinitely
SET
_ZZ_
50ms AH
_AH_
100ms AI
_AI_
200ms AJ
_AJ_
300ms AK
_AK_
400ms AL
_AL_
500ms AM
_AM_
600ms AN
_AN_
Indefinitely AG
_AG_
END
_ZZ_
