OPTICON Universal menu book
U15
2.2. Keyboard wedge/USB options
This paragraph describes the options which are
relevant to readers with a wedge or USB
interface. The following parameters can be
configured:
• keyboard language
• special options
• intercharacter delay
Because these options are interdependent, it is
important to perform the configuration in the
sequence given.
Please consult your sales office for keyboard
layouts and language currently supported.
Keyboard wedge operation modes:
This mode enables or disables responses from
PC wedge to the computer during booting.
In normal cases, the keyboard handles the
responses to the computer. The PC wedge is
only listening in order to be aware of the
keyboard state.
With keyboard:
Use this mode in case a keyboard is connected
to the PC wedge Y-cable.
The wedge is only listening in case the
computer is booting or when the wedge is idle.
Without keyboard:
Use this mode in case no keyboard is
connected to the PC wedge Y-cable. In some
cases this mode is required in case only a PC
USB keyboard is connected. If this option is
enable, the computer can detect the wedge as
a keyboard. In case the computer reports a
keyboard error or in case no data is displayed,
try this option. It is required to power OFF the
PC, wait 10 seconds and power ON the PC
again. Do not enable this option in case a
keyboard is connected to the Y-cable.
The wedge is responding to all commands from
the computer.
The ‘without keyboard’ option is only supported
for PC/AT wedges.
SET
_ZZ_
With keyboard KM
_KM_
Without keyboard KL
_KL_
END
_ZZ_
