MAGNA-LOC
SECTION PROPERTIES AND LOAD TABLES
Factory Applied Sealant
16" or 18" Coverage
(Flat)
.10"
2"
C
MAGNA-LOC SECTION PROPERTIES
GAUGE
WIDTH
in
YIELD
ksi
WEIGHT
psf
TOP IN COMPRESSION
BOTTOM IN COMPRESSION
Ixx
in
4
/ft
Sxx
in
3
/ft
Ma
(k-in)/ft
Ixx
in
4
/ft
Sxx
in
3
/ft
Ma
(k-in)/ft
24
16"
50
1.25
.1785
.1013
3.03
0.0855
0.0754
2.69
22
16"
50
1.63
.2468
.1419
4.25
0.1178
0.1066
3.59
24
18"
50
1.21
.1620
.0900
2.69
0.0760
0.0669
2.40
22
18"
50
1.58
.2233
.1255
3.76
0.1047
0.0947
3.19
1. Theorectical section properties have been calculated per AISI 2001 "Specification for the Design of Cold-formed Steel Structural
Members." Ixx and Sxx are effective section properties for deflection and bending.
2. Allowable load is calculated in accordance with AISI 2001 specifications considering bending, shear, combined bending and shear,
deflection, and ASTM 1592 testing. Allowable load considers the worst case of 3 and 4 equal span conditions. Allowable load does not
address web crippling or fasteners/support connection and panel weight is not considered.
3. Deflection consideration is limited by a maximum deflection ratio of L/180 of span.
4. Allowable loads do not include a 1/3 stress increase in uplift.
ALLOWABLE UNIFORM LIVE LOADS PSF
2 or more Equal Spans
GAUGE
WIDTH
in
YIELD
ksi
WEIGHT
psf
Inward Load
Outward Load
2.5' 3' 3.5' 4' 4.5' 5' 2.5' 3' 3.5' 4' 4.5' 5'
24
16"
50
1.35
283 206 156 122
97
80
410 300 229 180 144 119
22
16"
50
1.74
401 287 215 167 133 108 609 440 332 259 207 169
24
18"
50
1.31
252 183 139 108
87
71
364 267 203 160 128 105
22
18"
50
1.69
356 255 191 148 118
96
539 390 294 229 183 150
ALLOWABLE UNIFORM LIVE LOADS PSF
3 or more Equal Spans
GAUGE
WIDTH
in
YIELD
ksi
WEIGHT
psf
Inward Load
Outward Load
2.5' 3' 3.5' 4' 4.5' 5' 2.5' 3' 3.5' 4' 4.5' 5'
24
16"
50
1.35
161 126 101
82
68
57
65
60
55
50
45
40
22
16"
50
1.74
257 197 155 125 103
86
86
80
73
67
61
55
24
18"
50
1.31
144 112
89
73
61
51
68
62
56
50
43
37
22
18"
50
1.69
160 128 104
87
74
63
78
73
68
62
57
52
