Metal Sales Magna-Loc Installation - Manual (Page 19)

© Metal Sales Manufacturing Corporation / Subject to change without notice 6/12
19
MAGNA-LOC
BOX GUTTER END
24 ACG 5708141 (Left) .24 lbs
5708241 (Right)
24 PVDF 58081_ _ (Left) .24 lbs
58082_ _ (Right)
5"
1"
1"
4"
5"
C
24 ACG 5781241 (Left) .24 lbs
5781341 (Right)
24 PVDF 58812_ _ (Left) .24 lbs
58813_ _ (Right)
SCULPTURED
GUTTER END
5 1 /
2
"
4"
100°
6 5 /
8
"
C
SSR GUTTER DRIP
24 ACG 5778141 8.70 lbs 10'-2"
24 PVDF 58781_ _ 8.70 lbs 10'-2"
4 1 /
2
"
C
X*
3"
Hem
* See chart on page 7
24 ACG 5709841 16.95 lbs 10'-2"
24 ACG 5710141 33.90 lbs 20'-3"
24 PVDF 58098_ _ 16.95 lbs 10'-2"
24 PVDF 58101_ _ 33.90 lbs 20'-3"
4” x 6” DOWNSPOUT
4"
6"
C
24 ACG 5709441 12.90 lbs 10'-2"
24 ACG 5709741 25.80 lbs 20'-3"
24 PVDF 58094_ _ 12.90 lbs 10'-2"
24 PVDF 58097_ _ 25.80 lbs 20'-3"
3 1/2” x 4” DOWNSPOUT
4"
C
3
1 /
2
"
24 ACG 5781441 .25 lbs 0'-10"
24 PVDF 58814_ _ .25 lbs 0'-10"
SSR GUTTER SUPPORT
1"
7 /
8
"
C
3 /
4
"
3 /
8
"
Hem
24 ACG 5709241 .36 lbs 1'-4"
24 PVDF 58092_ _ .36 lbs 1'-4"
UNIVERSAL GUTTER/
DOWNSPOUT STRAP
Hems
A-A
1 1 /
2
"
16"
C
A
A
GAUGE FINISH PRODUCT NO. WT
GAUGE FINISH PRODUCT NO. WT
GAUGE FINISH PRODUCT NO. WT LENGTH
GAUGE FINISH PRODUCT NO. WT LENGTH
GAUGE FINISH PRODUCT NO. WT LENGTH
GAUGE FINISH PRODUCT NO. WT LENGTH
GAUGE FINISH PRODUCT NO. WT LENGTH
FLASHING PROFILES (CONT.)
