APPENDIX C - USER SETTING RECORD
PARAMETER MENU: USER SETTING RECORD
PARAMETER
NUMBER
PARAMETER
NAME
FACTORY
DEFAULT
USER
SETTING
0 LINE VOLTS AUTO
1 PRESET #1 20.00 Hz
2 PRESET #2 20.00 Hz
3 PRESET #3 20.00 Hz
4 PRESET #4 20.00 Hz
5 SKIP FREQ #1 .00 Hz
6 SKIP FREQ #2 .00 Hz
7 BANDWIDTH 1.00 Hz
8 ACCEL RATE 30.0 SEC
9 DECEL RATE 30.0 SEC
10 MINIMUM FREQ .50 Hz
11 MAXIMUM FREQ 60.00 Hz
12 DC BRAKE VOLT .0 VDC
13 DC BRAKE TIME .0 SEC
14 DYNAMIC BRAKE OFF
16 CURRENT LIMIT 120 %
17 MOTOR OVRLOAD 100%
18 BASE FREQ 60.00 Hz
19 FIXED BOOST (NOTE 1)
22 TORQUE CONSTANT
23 CARRIER FREQ 2.5 kHz
24 AUTO SOURCE 4-20 mA
