42 13435744_EDBMH01_v13
17 PARAMETER MENU
Contained in this section is a list of the MCH Series parameters in ascending numnerical
order. Refer to Section 18 DESCRIPTION OF PARAMETERS for full information on
each parameter.
PARAMETER MENU
PARAMETER
NUMBER
PARAMETER
NAME
RANGE OF
ADJUSTMENT
FACTORY
DEFAULT
0 LINE VOLTS
HIGH
LOW
AUTO
AUTO
1 PRESET #1 (NOTE 1) 20.00 Hz
2 PRESET #2 (NOTE 1) 20.00 Hz
3 PRESET #3 (NOTE 1) 20.00 Hz
4 PRESET #4 (NOTE 1) 20.00 Hz
5 SKIP FREQ #1 .00 Hz - MAXIMUM FREQ .00 Hz
6 SKIP FREQ #2 .00 Hz - MAXIMUM FREQ .00 Hz
7 BANDWIDTH .00 - 10.00 Hz 1.00 Hz
8 ACCEL RATE (NOTE 1) 30.0 SEC
9 DECEL RATE (NOTE 1) 30.0 SEC
10 MINIMUM FREQ .00 - MAXIMUM FREQ .50 Hz
11 MAXIMUM FREQ MINIMUM FREQ - 120.0 Hz 60.00 Hz
12 DC BRAKE VOLT (NOTE 1) .0 VDC
13 DC BRAKE TIME .0 - 999.9 SEC .0 SEC
14 DYNAMIC BRAKE OFF, ON OFF
16 CURRENT LIMIT 25 - 120 % 120 %
17 MOTOR OVRLOAD 25 - 100 % 100%
18 BASE FREQ 20.00 - 360.0 Hz 60.00 Hz
19 FIXED BOOST .0 - 30.0 % (NOTE 1)
22 TORQUE
CONSTANT
VARIABLE
CONST / NO COMP
CONSTANT
23 CARRIER FREQ 2.5, 6, 8, 10, 12, 14 kHz 2.5 kHz
24 AUTO SOURCE
KEYPAD
0-10 VDC
4-20 MA
PRESET #1
PRESET #2
PRESET #3
PRESET #4
MOP
SELECTED
4-20 MA
NOTE 1: REFER TO SECTION 18.0 - DESCRIPTION OF PARAMETERS.
