Lenze MCH Series - Manual (Page 11)

13435744_EDBMH01_v13 7
HP
(kW)
INPUT
VOLTAGE
MODEL H W D N P Q R S
10
(7.5)
240 / 200 MH2100B 11.25 7.86 6.84 3.93 4.19 2.00 7.75 1.38
480 / 400 MH4100B 9.38 7.86 6.84 3.93 4.19 2.00 5.88 1.13
590 MH5100B 9.38 7.86 7.40 3.93 4.19 2.00 5.88 1.13
15
(11)
240 / 200 MH2150B 12.75 7.86 6.84 3.93 4.19 2.00 9.25 1.38
480 / 400 MH4150B 11.25 7.86 6.84 3.93 4.19 2.00 7.75 1.38
590 MH5150B 12.75 7.86 6.84 3.93 4.19 2.00 9.25 1.38
20
(15)
240 / 200 MH2200B 12.75 10.26 7.74 5.13 5.00 2.50 9.25 1.38
480 / 400 MH4200B 12.75 7.86 6.84 3.93 4.19 2.00 9.25 1.38
590 MH5200B 12.75 7.86 7.40 3.93 4.19 2.00 9.25 1.38
25
(18.5)
240 / 200 MH2250B 15.75 10.26 8.35 5.13 5.00 2.50 12.25 1.38
480 / 400 MH4250B 12.75 10.26 7.74 5.13 5.00 2.50 9.25 1.38
590 MH5250B 12.75 10.26 7.74 5.13 5.00 2.50 9.25 1.38
30
(22)
240 / 200 MH2300B 15.75 10.26 8.35 5.13 5.00 2.50 12.25 1.38
480 / 400 MH4300B 12.75 10.26 7.74 5.13 5.00 2.50 9.25 1.38
590 MH5300B 12.75 10.26 8.25 5.13 5.00 2.50 9.25 1.38
40
(30)
480/400 MH4400B 15.75 10.26 8.35 5.13 5.75 2.50 12.25 1.38
590 MH5400B 15.75 10.26 8.35 5.13 5.75 2.50 12.25 1.38
50
(37.5)
480 / 400 MH4500B 19.75 10.26 8.55 5.13 5.75 2.50 16.25 1.75
590 MH5500B 19.75 10.26 8.55 5.13 5.75 2.50 16.25 1.75
60
(45)
480 / 400 MH4600B 19.75 10.26 8.55 5.13 5.75 2.50 16.25 1.75
590 MH5600B 19.75 10.26 8.55 5.13 5.75 2.50 16.25 1.75
TYPE 1 DIMENSIONS (continued)
