13.2.3 MCH DISPLAY IN FAULT MODE
When the drive trips on a fault, the display will automatically change to the FAULT
display and the FAULT MESSAGE will be indicated.
DRIVE
STATUS
SPEED
SETPOINT
FAULT > 60.00 HZ
OVERLOAD HAND
FAULT
MESSAGE
HAND/OFF/AUTO
STATUS
SPEED
UNITS
DIRECTION
(FORWARD)
In FAULT mode, the ENTER key will toggle the display between three screens: FAULT,
% LOAD and VAC. The DRIVE STATUS for these displays will be FAULT. Illustrated
herein is an example of the drive in the FAULT mode displaying % LOAD.
DRIVE
STATUS
SPEED
SETPOINT
FAULT > 60.00 HZ
0 % LOAD HAND
FAULT
MESSAGE
HAND/OFF/AUTO
STATUS
SPEED
UNITS
DIRECTION
(FORWARD)
NOTE
To clear a FAULT, press the OFF (STOP) key, issue a remote STOP
command at TB-1 or use TB-13D (refer to Parameter 50 - TB13D
INPUT).
