4.4
TYPE 4, 4X & 12 DIMENSIONS (Models up to 30HP)
The figure and table herein provide the dimensions for MCH Type 4, 4X & 12 models
rated up to 30 HP at 240/200 Vac AND 60 HP at 480/400 Vac and 590 Vac.
1.00"
W
H
R
T
D
Mounting Tab Detail
V
Dia. Slot
Conduit Holes:
S Dia.
0.88" Dia.
S Dia.
N
P
Q
Q
R
W
U
IF W = 7.86"
T = 0.20"
U = 0.34"
V = 0.19"
IF W = 10.26"
IF W = 13.72"
T = 0.28"
U = 0.44"
V = 0.24"
HP
(kW)
INPUT
VOLTAGE
MODEL*
H
W
D
N
P
Q
R
S
1
240 / 200
MH210
7.88
6.12
4.35
3.06
2.70
1.37
5.88
0.88
(0.75) 480 / 400
MH410
7.88
6.12
4.35
3.06
2.70
1.37
5.88
0.88
590
MH510
7.88
6.12
4.35
3.06
2.70
1.37
5.88
0.88
2
240 / 200
MH220
7.88
7.86
4.90
4.80
3.25
1.37
5.88
0.88
(1.5) 480 / 400
MH420
7.88
7.86
4.90
4.80
3.25
1.37
5.88
0.88
590
MH520
7.88
7.86
4.90
4.80
3.25
1.37
5.88
0.88
3
240 / 200
MH230
7.88
7.86
5.90
4.80
4.25
1.37
5.88
0.88
(2.2) 480 / 400
MH430
7.88
7.86
4.90
4.80
3.25
1.37
5.88
0.88
590
MH530
7.88
7.86
4.90
4.80
3.25
1.37
5.88
0.88
5
240 / 200
MH250
9.75
10.26
7.20
5.13
5.25
2.00
7.75
1.13
(3.7) 480 / 400
MH450
7.88
7.86
5.90
4.80
4.25
1.37
5.88
0.88
590
MH550
7.88
7.86
5.90
4.80
4.25
1.37
5.88
0.88
7.5
240 / 200
MH275
11.75
10.26
8.35
5.13
5.75
2.00
9.75
1.13
(5.5) 480 / 400
MH475
9.75
10.26
7.20
5.13
5.25
2.00
7.75
1.13
590
MH575
9.75
10.26
7.20
5.13
5.25
2.00
7.75
1.13
