Once the desired speed is reached, release the contact and the drive speed will hold
at that value. The DECREASE FREQ function will work when the drive is in a STOP
or RUN mode. The INCREASE FREQ function will only work while the drive is in a
RUN mode.
If HAND SOURCE and/or AUTO SOURCE is set to SELECTED, TB-13A and TB-13B
can be programmed for this function. Program TB-13A (Parameter 47) to DECREASE
FREQ, and TB-13B (Parameter 48) to INCREASE FREQ. Refer to the description of
operation in the preceding paragraph.
NOTE
If TB-13A, TB-13B and TB-13C are all programmed to select speed
references, and two or three of the terminals are closed to TB-2,
the higher terminal has priority and will override the others. For
example, if TB-13A is programmed to select 0-10VDC, and TB-13C
is programmed to select PRESET #3, closing both terminals to TB-2
will cause the drive to respond to PRESET #3 because TB-13C
overrides TB-13A.
14.2.5 ANALOG OUTPUT SIGNALS
There are two terminals that can supply analog output signals proportional to output
frequency and load. Terminal TB-10A can provide a 0-10 VDC or a 2-10 VDC signal
proportional to output frequency, and TB-10B can provide the same signals proportional
to load. The 2-10 VDC signals can be converted to a 4-20 mA signal using a resistor
in series with the signal such that the total circuit resistance is 500 Ohms. For more
information, refer to Parameters: 42 - TB10A OUTPUT, 43 - TB10A SCALING, 44 -
B10B OUTPUT and 45 - TB10B SCALING in Section 18.0 - DESCRIPTION OF
PARAMETERS.
14.2.6 DRIVE STATUS OUTPUTS
The control board has one Form C relay at terminals TB-16, TB-17 and TB-18. Contacts
are rated 2 amps at 28 VDC or 120 Vac.
There are also two open-collector outputs at terminals TB-14 and TB-15. The open-
collector circuit is a current-sinking type rated at 30 VDC and 40 mA maximum. A power
supply (30 VDC max) must be used to power the open-collector outputs. The standard
drive does not have a power supply (a 24 VDC power supply is optional when the drive
is equipped with the Bypass option).
The Form C relay and open-collector outputs can be programmed for many different
status indications. Refer to Parameters 52 - TB14/RELAY #2, 53 - TB15/RELAY #3,
and 54 - RELAY #1.
NOTE
The Bypass option includes two Form C relays and a third is optional
(refer to Appendix A). When the drive is equipped with the Option
Box, there are two Form C relays and two open-collector outputs
(refer to Appendix B).
