13435744_EDBMH01_v13 29
DRIVE STATUS TABLE
DISPLAY DESCRIPTION
KSTOP KEYPAD STOP - The drive was stopped using the OFF (STOP) key.
RSTOP REMOTE STOP - The drive was stopped by opening TB-1 to TB-2.
SSTOP SERIAL STOP - The drive was stopped through the serial link.
RUN Drive is in RUN mode and is within + 0.5 Hz of the speed setpoint.
FAULT
Drive has shut down due to a FAULT condition. If the fault condition has
passed, pressing the HAND (OFF) key will clear the fault and return the
drive to the STOP mode.
LOCK Drive is in FAULT LOCKOUT after five unsuccessful restart attempts.
BRAKE DC BRAKE is energized.
LIMIT
Drive is in CURRENT LIMIT due to an overloaded motor, or ACCEL is set
too fast.
F DEC Drive is in DECEL FREEZE because DECEL is set too fast.
13.2.2 MCH DISPLAY IN RUN MODE
When the drive is in the RUN mode, the default display will look like this:
DRIVE
STATUS
SPEED
SETPOINT
RUN > 60.00 HZ
86 % LOAD HAND
LOAD
METER
HAND/OFF/AUTO
STATUS
SPEED
UNITS
DIRECTION
(FORWARD)
As in the STOP mode, the ENTER key can be used to toggle the display from % LOAD
to VAC (motor voltage):
DRIVE
STATUS
SPEED
SETPOINT
RUN > 60.00 HZ
460 VAC HAND
MOTOR
VOLTAGE
HAND/OFF/AUTO
STATUS
SPEED
UNITS
DIRECTION
(FORWARD)
NOTE
During acceleration and deceleration to the SPEED SETPOINT, the
DRIVE STATUS will show the actual drive speed. When the SPEED
SETPOINT is reached, the DRIVE STATUS will change to RUN (or
STOP if the drive is decelerating to a STOP).
