13435744_EDBMH01_v13 15
MH500 SERIES RATINGS
MODEL
INPUT OUTPUT
(480/590 Vac, 50 - 60 Hz) (0 - 460/575 Vac)
MODEL
NUMBER
(NOTE 1)
FOR MOTORS
INPUT
PHASE
NOMINAL NOMINAL
RATED CURRENT POWER CURRENT POWER
HP kW (AMPS) (KVA) (AMPS) (KVA)
MH510 1 0.75 3 1.9 / 1.9 1.9 1.6 / 1.6 1.6
MH520 2 1.5 3 3.3 / 3.3 3.4 2.7 / 2.7 2.7
MH530 3 2.2 3 4.6 / 4.6 4.7 3.9 / 3.9 3.9
MH551 5 3.7 3 7.1 / 7.1 7.3 6.1 / 6.1 6.1
MH575 7.5 5.5 3 10.5 / 10.5 10.7 9.0 / 9.0 8.8
MH5100 10 7.5 3 12.5 / 12.5 12.8 11.0 / 11.0 11.0
MH5150 15 11 3 19.3 / 19.3 19.7 17.0 / 17.0 16.9
MH5200 20 15 3 25 / 25 25.4 22 / 22 21.5
MH5250 25 18.5 3 31 / 31 31.2 27 / 27 26.9
MH5300 30 22 3 36 / 36 37.1 32 / 32 31.9
MH5400 40 30 3 47 / 47 47.5 41 / 41 40.8
MH5500 50 37.5 3 59 / 59 60.3 52 / 52 51.8
MH5600 60 45 3 71 / 71 72.5 62 / 62 61.7
NOTE 1: Refer to Section 3.0 for model number breakdown.
NOTE 2: Refer to Section 8.0 for recommended fuse type.
