Lenze MCH Series - Manual (Page 48)

44 13435744_EDBMH01_v13
PARAMETER MENU
PARAMETER
NUMBER
PARAMETER
NAME
RANGE OF
ADJUSTMENT
FACTORY
DEFAULT
41 AN INPUT FLTR 0.01 - 10.0 SEC 0.02 SEC
42 TB10A OUTPUT
NONE
0-10V
2-10V
NONE
43 TB10A SCALING 3.00 - 360.0 Hz 60.00 Hz
44 TB10B OUTPUT
NONE
0-10V
2-10V
NONE
45 TB10B SCALING 10 - 200 % 125 %
47 TB13A INPUT
NONE
0-10VDC
4-20MA
PRESET #1
DECREASE FREQ
REVERSE
NONE
48 TB13B INPUT
NONE
0-10VDC
4-20MA
PRESET #2
INCREASE FREQ
NONE
49 TB13C INPUT
NONE
0-10VDC
4-20MA
PRESET #3
HAND
REVERSE
NONE
50 TB13D INPUT
EXTERN FAULT
EXTERN /FAULT
EXTERN CLEAR
EXTERN FAULT
52 TB14/RELAY #2
NONE
RUN
FAULT
INVERSE FAULT
FAULT LOCKOUT
AT SPEED
ABOVE PRSET #3
CURRENT LIMIT
AUTO/HAND SRC
FOLLOWER PRES
MIN/MAX ALARM
INV MIN/MAX A
MIN ALARM
INV MIN ALARM
MAX ALARM
INV MAX ALARM
RUN REVERSE
NONE
