13435744_EDBMH01_v13 43
PARAMETER MENU
PARAMETER
NUMBER
PARAMETER
NAME
RANGE OF
ADJUSTMENT
FACTORY
DEFAULT
25 START METHOD
NORMAL
POWER UP
AUTO 1
AUTO 2
AUTO 3
NORMAL
26 STOP METHOD
RAMP
COAST
COAST
28 SPEED SRC KEY
ENABLED
DISABLED
ENABLED
29 HAND SOURCE
KEYPAD
0-10 VDC
4-20 MA
PRESET #1
PRESET #2
PRESET #3
PRESET #4
MOP
SELECTED
KEYPAD
30 CONTROL
NORMAL
NORM NO HAND
SERIAL SPEED
S SPD/NO HAND
SERIAL AUTO
S AUTO/NO HND
NORMAL
31 UNITS
speed: HERTZ, RPM, % HZ,
speed: HERTZ
/SEC, /MIN, /HR, GPH, NONE
pid: %, PSI, FPM, CFM, GPM, IN,
FT, /SEC, /MIN, /HR, F, C, MPM, GPH
32 HZ MULTIPLIER .10 - 650.0 1.00
33 UNITS DECIMAL
XXXXX
XXX.X
XX.XX
X.XXX
.XXXX
XXXXX
34 LOAD MULTIPLY 95 - 139 % 100%
35 LCD CONTRAST
LOW
MED
HIGH
MED
36 SLEEP THRSHLD .00 - 360.0 Hz .00 Hz
37 SLEEP DELAY .0 - 300 SEC 30.0 SEC
38 SLEEP BANDWID FB @ MIN - FB @ MAX 0%
39 TB5 MIN FREQ .00 - 360.0 Hz .00 Hz
40 TB5 MAX FREQ .00 - 360.0 Hz 60.00 Hz
