11
HP
(kW)
INPUT
VOLTAGE
MODEL*
H
W
D
N
P
Q
R
S
10
240 / 200
MH2100
13.75
10.26
8.35
5.13
5.75
2.00
11.75
1.38
(7.5) 480 / 400
MH4100
11.75
10.26
8.35
5.13
5.75
2.00
9.75
1.13
590
MH5100
11.75
10.26
8.35
5.13
5.75
2.00
9.75
1.13
15
240 / 200
MH2150
15.75
10.26
8.35
5.13
5.75
2.00
13.75
1.38
(11) 480 / 400
MH4150
13.75
10.26
8.35
5.13
5.75
2.00
11.75
1.38
590
MH5150
13.75
10.26
8.35
5.13
5.75
2.00
11.75
1.38
20
240 / 200 MH2200D 15.75
10.26
8.35
5.13
5.75
2.00
11.75
1.38
(15) 480 / 400
MH4200
15.75
10.26
8.35
5.13
5.75
2.00
13.75
1.38
590
MH5200
15.75
10.26
8.35
5.13
5.75
2.00
13.75
1.38
25
240 / 200 MH2250D 20.25
10.26
8.35
5.13
5.75
2.00
16.25
1.38
(18.5) 480 / 400 MH4250D 15.75
10.26
8.35
5.13
5.75
2.00
11.75
1.38
590
MH5250D 15.75
10.26
8.35
5.13
5.75
2.00
11.75
1.38
30
240 / 200 MH2300D 20.25
10.26
8.35
5.13
5.75
2.00
16.25
1.38
(22) 480 / 400 MH4300D 15.75
10.26
8.35
5.13
5.75
2.00
11.75
1.38
590
MH5300D 15.75
10.26
8.35
5.13
5.75
2.00
11.75
1.38
40
480 / 400 MH4400D 20.25
10.26
8.35
5.13
5.75
2.00
16.25
1.38
(30)
590
MH5400D 20.25
10.26
8.35
5.13
5.75
2.00
16.25
1.38
50
480 / 400 MH4500D 21.00
13.72
8.35
5.13
6.10
2.00
16.25
1.38
(37.5)
590
MH5500D 21.00
13.72
8.35
5.13
6.10
2.00
16.25
1.38
60
480 / 400 MH4600D 21.00
13.72
8.35
5.13
6.10
2.00
16.25
1.38
(45)
590
MH5600D 21.00
13.72
8.35
5.13
6.10
2.00
16.25
1.38
* MODELS WITH BLANK ENCLOSURE DESIGNATION ARE AVAILABLE IN NEMA 4
(INDICATED BY “C”) OR 4X STAINLESS STEEL (INDICATED BY “E”).
TYPE 4, 4X, AND 12 DIMENSIONS (continued)
