M0233-01 Model 3700
1-4 Rev. 12/12
TM
Specifications
Specifications
Specification air Seed delivery (aSd)
Number of Rows 24R 20 24R 22 24R N 30 36R N 20
Row Spacing 20" 22" 30" 20"
Weight Empty (Mechanical) 19,700 lb 19, 900 lb 25, 241 lb 26,872 lb
Weight Empty (EdgeVac) 21,100 lb 21, 300 --- ---
Transport Height 13'-0" 13'-0" 13'-0" 13'-0"
Planting Length 27'-4" 27'-4" 30'-11" 30'-11"
Transport Length 32'-0" 32'-0" 36'-11" 40'-2"
Planting Width 43'-11" 47'-11" 62' 9" 63' 9"
Transport Width (14'-0" with granular
chemical option) 13'-8" 13'-8" 13'-8" 13'-8"
Seed Capacity 110 bu.
ASD Fill Dimensions (planting position) 8' 7"
Transport Tire Size (4) 36 x 16-17.5 rib duplex 14-ply tubeless
Transport Tire Pressure 75 psi
Wing/Lift Tires (4 - 24R, 6 - 36R) 7.5" x 20", 8-ply, Tubeless Rib Implement
Field Tire Pressure 40 psi
Contact Drive Tires (4) 4.80 x 8"
Piston Pump Drive Tires (Optional) (2) 7.60" x 15"
Field Lift Four Master/Two Slave Hydraulics
Row Markers Independently controlled, three stage, low profile equipped disk blade depth
bands.
Tractor Hydraulic Requirements
Configuration requirements description
Base machine with mechanical meters 2 SCV 15 gpm #1 SCV: planter lift
#2 SCV: markers / fold (with 12v control console)
Base machine with mechanical meters
Air seed delivery (ASD) system 3 SCV 25 gpm #1 SCV: planter lift
#2 SCV: markers / fold (with 12v control console)
#3 SCV: ASD system
Base machine with EdgeVac meters
Tractor mounted PTO hydraulic pump 2 SCV 15 gpm #1 SCV: planter lift
#2 SCV: markers / fold (with 12v control console)
nOTe: Tractor-mounted pTO hydraulic pump supplies oil flow for edgevac hydraulic circuit.
