Model 3700 M0233-01
Rev. 10/11 2-19
Machine Operation
2. Install cylinder lockups on marker cylinders to prevent markers from unfolding when not in use or planter is in
transport position.
row marker safety lockup stored row marker safety lockup installed
raising planter
3. Hold RAISE/WING LOCK switch on control console in raiSe while operating proper tractor hydraulic control
to raise planter. Planter frame should raise level until lift (master) cylinders at ends of wings are fully extended.
Center lift (slave) cylinders will continue to extend (at a somewhat slower rate) until they are fully extended.
