Page 155
TM
Model 3700
M0233-01
Rev. 6/14
5-59
Lubrication and Maintenance
Adapter Clutch Driver Cable
(iSObUS Only)
eLeCTriC CLUTCh SCheMaTiC
Electric Clutches
Section Adapter Cable
Interplant Cable
Clutch Cable
Connects to interplant
electric clutch
RC
R1
R2
R3
Signal
rC wire/Color
r1
r2
r3
Load Power
1
Red
1
1
1
Load Ground
2
Black
4
4
4
PWM 1 Power
3
Red/Green
-
-
-
PWM 1 Ground
47 Black/Green
-
-
-
PWM 2 Power
52 Red/Yellow
-
-
-
PWM 2 Ground
67 Black/Yellow
-
-
-
PWM 3 Power
72 Red/Blue
-
-
-
PWM 3 Ground
87 Black/Blue
-
-
-
Meter Speed 1
93 Green
-
-
-
Meter Speed 2
10 Green
-
3
-
Meter Speed 3
11 Green/Red
-
-
3
iSObUS CabLe raTe COnTrOL
