M0233-01 Model 3700
6-2 Rev. 10/11
TM
Troubleshooting
LifT CirCUiT
prObLeM pOSSibLe CaUSe SOLUTiOn
Field turn around toolbar
height is not 39”-41”. Stroke limiter valve is out of adjustment. Consult your Kinze Dealer for
service.
Planter not leveling out when
lowering from transport. Detent lever valve out of adjustment. Consult your Kinze Dealer for
service.
Planter settles. Lift cylinder leaking. Repair or replace cylinder.
KpM iii eLeCTrOniC Seed MOniTOr
prObLeM pOSSibLe CaUSe SOLUTiOn
Single sensor communication
alarm
comes on.
Faulty seed tube sensor. Replace sensor.
Break in the harness just before
the seed tube sensor.
Inspect for break in harness and repair.
If break can't be found, replace harness
section.
Dirty or corroded connector. Clean connector.
Sensor communication alarms
come on for all sensors.
Faulty monitor. Repair/Replace monitor.
Break in the harness just after the
monitor.
Inspect for break in harness and repair.
If break can't be found, replace harness
section.
Dirty or corroded connector. Clean connector.
Sensor communication alarms
come on for some sensors.
Break in the harness. Inspect for break in harness and repair.
If break can't be found, replace harness
section corresponding with alarming
sensors.
Dirty or corroded connector. Clean connector.
Faulty monitor values (such as
speed, area, etc.) being
displayed.
Incorrect monitor settings. Change settings to properly correspond to
the system.
Faulty radar/magnetic distance sensor. Replace sensor.
Improperly mounted radar sensor. Properly mount sensor.
Underplanting or no planting
alarm on a single sensor when
planting (alarm on with a single
bargraph segment on and a
flashing row number on a single
row.
Seed tube sensor is blocked. Clean sensor.
Faulty seed tube sensor. Replace sensor.
Meter not planting or underplanting. Repair/replace meter.
Chain broken or off sprocket. Repair as necessary.
Seed tube sensor dirty or
blocked
warning comes on.
Seed tube sensor is dirty. Clean sensor.
Faulty seed tube sensor. Replace sensor.
LED on seed tube sensor will
not come on.
Faulty seed tube sensor. Replace sensor.
Dirty or corroded connector. Clean connector.
Break in the harness just before the
sensor.
Repair harness.
Erroneous MPH readings at idle.
(Radar Distance Sensor Only)
Radar sensor not located in a stable
location.
Relocate to a more stable location.
