M0233-01 Model 3700
3-20 Rev. 10/11
TM
Row Unit Operation
Straight drop in-furrow placement 4½" slope-compensating bander 14" rear banding
granULar CheMiCaL banding OpTiOnS
Granular chemical banding options allow 4½" slope-compensating banding, straight drop in-furrow placement or 14"
rear banding.
nOTe: granular chemical rear bander is not compatible with covering discs/single press wheel option.
Optional granular chemical bander shield is installed on underside of wheel arm stop to shield crop residue from
lodging in granular chemical bander.
granULar CheMiCaL bander ShieLd
⅜ "-16 x 1½" hex
head cap screw
Wheel arm stop Bander shield
Hardened washer
