6 Appendix
30
Direct current
6.1.3 Measuring circuit monitoring
Connection type Resistance transmitter: 3-wire circuit
(A = Start, S = Slider, E = End)
Resistor/potentiometer: 2-wire circuit, 3-wire circuit, and 4-wire circuit
Sensor lead resistance  11  per line for 2-wire circuit, 3-wire circuit, and 4-wire circuit
Designation Measuring range Measuring accuracy
Designation Measuring range Accuracy a Input resistance
Input for mV generator -100 to 1100 mV ±0.05 % R
E
 1 M
a The accuracy value refers to the complete measuring range.
Type 707050 Type 707051
Underrange Linear drop up to 3.8 mA Linear drop up to 3.8 mA
(According to NAMUR recommendation
43) (According to NAMUR recommendation
43)
Linear drop up to -0.12 V
Overrange Linear increase up to 20.5 mA Linear increase up to 20.5 mA
(According to NAMUR recommendation
43) (According to NAMUR recommendation
43)
Linear increase up to 10.31 V
Probe short-circuit/probe and
cable break RTD temperature probe: (configurable) RTD temperature probe: (configurable)
 3.6 mA,  21.7 mA  3.6 mA,  21.7 mA
Or free setting: 3.6 mA to 23 mA Or free setting: 3.6 mA to 23 mA
 -0.2 V,  11.0 V
Or free setting: -0.25 V to 11.875 V
Thermocouple: (configurable)
a
Thermocouple: (configurable)
a
 3.6 mA,  21.7 mA  3.6 mA,  21.7 mA
Or free setting: 3.6 mA to 23 mA Or free setting: 3.6 mA to 23 mA
 -0.2 V or  11.0 V
Or free setting: -0.25 V to 11.875 V
Current limiting in the event of
a probe short circuit or probe
break  23 mA
a For thermocouples and mV generator a probe short-circuit detection is not possible.
