7
1 Introduction
1.4 Dimensions
1.4.1 dTRANS T05 B (707050) transmitter
1.4.2 dTRANS T05 T (707051) transmitter
5
Ш
44
Ш
7 Ш
33 21
This figure shows type 707051 installed on a TH 35-7.5 DIN rail. The specifications concerning dimen-
sions are only valid for installation on this DIN rail and change accordingly if a TH 35-15 DIN rail is
used.
101.2
102.5 6.3
93.1
