68
E
PARTS AND ACCESSORIES SUPPLIED
Scope of supply
Your LABOROTA 20 cartons contain the parts and accessories as listed below. Before disposing
of the carton, check the contents for all items on the below parts list.
We recommend to keep packing material for future use.
Item P/N qty. for more details
refer to page
LABOROTA 20 S A control automatic 518-17100-00 1
or
LABOROTA 20 S A O control automatic 518-17200-00 1
LABOROTA 20 E A control automatic 518-27100-00 1
LABOROTA 20 E A O control automatic 518-27200-00 1
LABOROTA 20 S A control automatic
without vacuumpump
518-17110-00
1
LABOROTA 20 S A O control automatic
without vacuumpump
518-17210-00
1
LABOROTA 20 E A control automatic
without vacuumpump
518-27110-00
1
LABOROTA 20 E A O control automatic
without vacuumpump
518-27210-00
1
Glas set-A (control automatic II) 15-300-006-32 1 page 84
Large coupling 11-300-003-71 1 Page 77, (1)
Large split ring 23-30-01-02-31 1 Page 77, (13)
PTFE O-ring 23-30-01-01-11 1 Page 77, (5)
PTFE-adapter 23-30-01-02-29 1 Page 77, (4)
PTFE-seal 23-30-01-01-51 1 Page 77, (6)
Backing ring 23-30-01-02-28 1 Page 77, (7)
Small split ring 23-30-01-02-27 1 Page 77, (11)
Small coupling 11-300-003-18 1 Page 77, (2)
Transportation rod 22-30-01-03-17 2 page 76
Cap 11-300-003-28 4 Page 76, (5)
Tube-Set 591-34000-00 1
Vapour Temperature Sensor 14-014-003-06 2 page 119 and 120
Vacuum Pump MD4C+AK+EK 591-07200-00 1 only pos. 1 - 4
Instruction Manual 01-005-004-36 1
