USER’S GUIDE
5-20
120K Kit
120K Kit
When you see the following message on the LCD panel, you need to
replace the Drum Cleaner, Paper Discharger, Transfer Roller, the Paper
Feeding Roller, the Separator Pad and the Transfer Drum.
✒ Note
As for how to replace the Paper Feeding Roller, the Separator Pad and
the Transfer Drum, consult your local dealer/retailer.
We recommend you to consult the dealer where you purchased the
printer when you see following message on the LCD panel.
REPLACE 120K KIT
Drum Cleaner
!
Caution
The axis holder and bias element must be connected to install the Drum
Cleaner. Be sure to check the connection before you start replacement.
Replacing the Drum Cleaner
1. Press the Power button and turn the printer off.
2. Open the Top cover.
3. Remove the Drum Cover.
Fig. 5-23 Open the Covers
