ElmoMC AC Input Digital Servo Drives-Bassoon - Manual (Page 38)

Bassoon Installation Guide Installation
MAN-BASIG (Ver. 1.502)
www.elmomc.com
38
1
3
4
5
6
7
8
Encoder Feedback B - J2
SUPRET
+5v
CHB
CHA
2
2
Supply Voltage Return
+5v
BAS0025A
B
as
so
on INDEX
1
4
6
8
2
CHB
CHA
INDEX
Figure 23: Single-Ended Auxiliary Encoder inputs on J2 - Connection Diagram
