Bassoon Installation Guide Installation
MAN-BASIG (Ver. 1.502)
www.elmomc.com
16
Component Connector Described
in Section
Drawing
Main Feedback Cable J3 3.5.5
Auxiliary Feedback (if needed) J2 3.5.6
Digital Input Cable (if needed) J5 3.5.6
Digital Output Cable (if needed) J6 3.5.6
Communication Cables
(RS-232 and/or CANopen) J1, J8, J9 3.5.8
1
PC for drive setup and tuning
Motor data sheet or manual
