2.4. How to Use this Guide
In order to install and operate your Elmo Bassoon servo drive, you will use this manual in
conjunction with a set of Elmo documentation. Installation is your first step; after carefully
reading the safety instructions in the first chapter, the following chapters provide you with
installation instructions as follows:
•
Chapter 3, Installation
, provides step-by-step instructions for unpacking, mounting,
connecting and powering up the Bassoon.
•
Chapter 4, Technical Specifications
, lists all the drive ratings and specifications.
Upon completing the instructions in this guide, your Bassoon servo drive should be successfully
mounted and installed. From this stage, you need to consult higher-level Elmo documentation
in order to set up and fine-tune the system for optimal operation. The following figure
describes the accompanying documentation that you will require.
Figure 2: Elmo Documentation Hierarchy
As depicted in the previous figure, this installation guide is an integral part of the Bassoon
documentation set, comprising:
•
The Composer Software Manual, which includes explanations of all the software tools that
are part of Elmo’s Composer software environment.
•
The SimplIQ Command Reference Manual, which describes, in detail, each software
command used to manipulate the Bassoon motion controller.
•
The SimplIQ Software Manual, which describes the comprehensive software used with the
Bassoon.
