4.3 Initiate SDO Upload Protocol
This protocol is used to implement the Initiate SDO Download service.
Client to server:
0
1 4 8
7…5 4…0
css = 2 x m reserved
Server to client:
0
1 4 8
7…5 4 3…2 1 0
scs = 2 x n e s m reserved
where:
css
Client command specifier
2: Initiate upload request
scs Server command specifier
2: Initiate upload response
n Number of bytes in d that do not contain data. Only valid if
e = 1 and s = 1; otherwise it is 0. Bytes [8-n, 7] do not contain segment
data.
e Transfer type
0: Normal transfer
1: Expedited transfer
s Size indicator
0: Data set size is not indicated
1: Data set size is indicated
m Multiplexor. Represents index/sub-index of data to be transferred by
SDO.
d Data
e = 0, s = 0: d is reserved for future use.
e = 0, s = 1: d contains the number of bytes to be uploaded.
Byte 4 contains LSB and byte 7 contains MSB.
e = 1, s = 1: d contains data of length 4-n to be downloaded. The encoding
depends on the type of data referenced by index and sub-index.
e = 1, s = 0: d contains an unspecified number of bytes to be uploaded.
x Not used; always 0.
reserved Reserved for future use; always 0.
