Band (2) Select the band you want to use, two wireless routers must use the same setting.
Channel Select the channel you want to use, two wireless
Number (3) routers must use the same setting.
MAC address Input the MAC address of other wireless routers.
1 to 4 (4 - 7)
Set Click to set security settings for this connection
Security (8) (Please go to section ‘2-7-3 Wireless Security’
for detailed instructions).
2-7-1-4 Setup procedure for ‘AP Bridge – WDS’
In this mode, you can expand the scope of network by combining up to four other access points together, and
every access point can still accept wireless clients.
1
2
3
4
5
6
7
8
9
Here are descriptions of every setup items:
Band (2) Select the band you want to use, two wireless routers must use the same setting.
