5. Console Management in SNMP-FSH2602MG v2
71
AirLive SNMP-FSH2602MG v2 User’s Manual
3. Analysis port: Set the destination port of mirroring packet. All of the packets of
mirroring port will be duplicated and sent to Analysis port.
4. Use “Space” key to mark the mirroring port.
5. Select the .
When Mirroring state is in “Disable”,
it will not show any port state.
When Mirroring state is in “Tx”,
“Rx” or “Both”, it will show port
state for user to configure.
