4. Web Management in SNMP-FSH2602MG v2
47
AirLive SNMP-FSH2602MG v2 User’s Manual
2. Analysis Port: It means mirror port can be used to see all monitored port traffic. You
can connect mirror port to LAN analyzer or Netxray.
3. Monitor Port: The ports you want to monitor. All monitored port traffic will be copied to
mirror port. You can select max 25 monitor ports in the switch. User can choose which
port wants to monitor in only one mirror mode.
Note:
„ If you want to disable the function, you must select monitor port to none.
„ If the trunk group exists, you can see it in port menu (ex: Trunk. 1), and you also
can configure it for port mirroring configuration
If the trunk group
exists, you can see it in
port menu, and
configure it for port
mirroring configuration
